1000cd/M2 2.5mm SMD2121 Fixed LED Display 160x160mm Module Size

Brand Name : OEM

Model Number : OEM

Certification : CE ROHS FCC

Place of Origin : Shenzhen,China

Payment Terms : T/T, Western Union, MoneyGram

Delivery Time : 15-20 working days after deposit

Packaging Details : Standard wooden case or flight case packing as customer's request

MOQ : 1 square meter

Price : Negotiation

Supply Ability : 2500 square meters per month

Pitch : 2.5mm

Density : 160000

Module size : 160x160mm

Module resolution : 64x64 dots

LED standard : SMD2121

Brightness : ≥1000 cd/㎡

Viewing distance : 2-30m

Warranty period : 2 years

Contact Now

1000cd/㎡ 2.5mm SMD2121 Fixed LED Display 160x160mm Module Size​

Product Description

  • Light weight: 9~12 kg/cabinet .
  • High contrast,ideal gray scale,presenting the Clear and bright pictures;
  • LED Screen cabinet is made of die-casting aluminum material, The good effect of heat dissipation；
  • High Contrast ratio: 4000:1 , Which is a very high level to ensure a vivid image of our LED display screen system.
  • Angle adjustable -10 degree to +10 degree, Inside curved or outside curved both available;
  • With magnets can be front service ;
  • Can connect to nearly any equipment, including laptops, PCs, DVD or Blu-ray, tablets and cameras and so on ;

ITME SPECIFICATION
Unit Module Pixel Pitch:2.5mm
Pixel Density: 160000 Dots/㎡
Trichromatic: 1R1G1B
Led chip spec:SMD2121
Module Size:(W)160mm*(H)160mm
Module resolution:W64×H64
Best View distance:≥ 2m
Viewing angle-Horizontal : 120±10 degree;
Viewing angle-Vertical :120±10 degree
Environment temperature:-40ºC ~ +85ºC
Working temperature: -20ºC ~ +50ºC
RH:10~90%
waterproof level:IP31
Module Weight: 220g/pc
Power Supply Working voltage: 220V±10%
Suitable voltage: DC5V
Average Power consumption:600W/㎡
Largest power consumption:1200W/㎡
Control System Computer : More than p4-80G/512m
Control system :WIN NT/XP/7
Control method :Novastar
Main Technical Parameter Scanning method:1/32 scanning
Frame frequency:≥60HZ
Refresh frequency:≥300HZ
Gray color:4096 lever,can display 16.7M colors
Brightness:≥1000cd/㎡
Brightness control lever:software can chance 100lever
Video signal :PAL/NTSC
Input/Output:8 input/8output
MTBF:≥10000H
life:100000H
Power:5V/40A
Protection Moisture/dust/ Resistant, electrostatic prevention, shockproof, meanwhile, against over-current, short-circuit, over-voltage and low voltage
Image performance Text,WORD,all formats of pictures(BMP/JPG/GIF/PCX...),as well as(MPG/MPEG/MPV/MPA/AVI/VCD/SWF/RM/RA/RMJ/ASF...)

Our service:

1. Enquiry response time: within 12 hours.
2. OEM&ODM: design and produce your customized requirements.
3. Provide distributors customized design and models we already have.
4. Protect your sales area, design idea and all your private information.
5. Top quality + reasonable price + patient after-sales service.
6. Brilliant Opto can also offer you LED stage display, LED outdoor video wall, wedding LED display, stage LED electronic screen and LED large screen full color display.

Application Case:

Widely used for shopping malls, entertainment venues, schools, government agencies, trade fair, fair, aiming at the exhibition, press conference, meeting rooms, cinemas, airports, hotels, internal, station waiting area, outdoor stadium, and a variety of public facilities and etc.
